Waterproof Night Vision Car Rear View backup Camera Special for Audi A3/A4 CA-865
> your car model.
> View angle:170°
> TV Lines:480
> Water-proof:IP68
> Minimum Illumination:0.1Lux
> Supply voltage : 12V ±4V
> Operating temperature :-20°C to+80°C
> Storage temperature: –40°C to +100°C
Information sur le produit h4>
Image Sensors
SONY CCD lens
color CMOS lens
IP rating
Ip68
Ip68
TV System
PAL or NTSC
NTSC or PAL
Effective Pixels
628× 582/628× 492
580× 540/580× 492
Sensing Area(mm)
4.9× 3.7
Resolution(TV Line)
480
420
Horizontal Sync Frequency (KHZ)
15.625/15.734
Vertical Sync Frequency (HZ)
50/60
Video output
1Vp-p, 75Ohm, RCA male
Gamma Consumption
0.45
AGC
Auto
BLC
Auto
S/N Ratio
Betterthan 48dB
Lens Angle (Deg. )
170° diagonal
Current Consumption (mA)
200
180
Power Supply (DCV)
12V
Operating Temperature (Deg. C)
-20~+70(RH95%MAX. )
Storage Temperature (Deg. C)
-40~+80(RH95%MAX. )
Size
Same as the number plate reversing lamp of the original car
LED lamp inside the camera (if camera has built-in LED light)
Power Supply (DCV)
12V
Light color
Thin yellow
Current Consumption (mA)
30~60mA
Operating Temperature
-20~+100
Storage Temperature
-40~+120
